Housing for the panel :

Light  and frame is made of high quality iron , rust and oil removed, under anti-rust treated and rust proof for 8-10 years under normal  application

With white/black  powder coating

Diffuser for the panel :

Polycarbonate, Acrylic ,Prismatic Led  Diffuser Specially for LED

LED type for the panel :

It use led module in SMD2835

Electrical for the panel :

Philips, Tridonic in AC220-240v  or Arcata -X-power in AC120-277v  standard /Dimmable /Dali driver  for LED line

Mounting for the panel :

Surface mounting, suspended type.

Main applications:

1, Hotel / Hospital / Shopping mall

2, Conference & Meeting room  /Factory / Office

3, Residential Home / Institution Building

4, School / College  & University

Advantages:

High efficiency save energy

The light from the Led light is released through the diffuser directly, which isn't absorbed and reflected from other media. So the utilization of the

Light is relatively high,and the overall luminious efficiency of  light   is quiet higher. Energy saving, saving 65% than the traditional lights at the same brightness.

Save cost

The components of direct light panel is simpler than ordinary panel, it will save the guide-plate and overall cost will be more effective.

Luminous uniformity

Direct  light panel is designed to use the LED luminescence to make a reasonable LED distance,  with the diffusion  and the height of the light fixtures to achieve

The ideal blend of light, because the light SMD are  arranged in a matrix, so the reasonable distance between the led SMD and the PC diffuser, so that the light

Doesn't have a dark zone, and it iimproves the brightness uniformity when it's lighting up.

Long life

Direct light panel is compared with the side light panel , it has a certain distance between the LED SMD and  the diffuser.

The heat dissipation provides enough space to ensure the long life of the light. The light life has more than 50000hrs

 SPECIFICATIONS:
